Xray X12'26 - 1/12Th Scale Pan Car - Xy370022

Xray x12'26 - 1/12 pan car

Description

The xray x12'26 represents a calculated step forward in 1/12 scale racing technology, offering a collection of specific refinements for the competitive driver. The core of the 2026 version is its redesigned aluminium chassis, which has been altered to lessen flex at the rear. This change results in a car with more predictable stability and better traction when exiting corners, allowing for earlier power application. The car's handling is further sharpened by adjustments to the suspension geometry. A new pod and side link mounting system provides multiple positions to ensure the suspension moves smoothly without binding as it compresses, keeping the tyres in consistent contact with the track surface for a more connected feel

Every update on the x12'26 is designed to address the fine details that separate finishing positions in high-level racing. The front end now features wider lower arms and a thinner carbon brace, a combination that makes the car's steering response more forgiving while increasing mechanical grip. New aluminium pivot holders allow for a lower roll-centre, and the addition of a floating servo mount provides another tool for tuning chassis flex and feel. These individual adjustments work together to create a car that is not only quick, but also more consistent and easier to drive at the limit, giving the driver the confidence needed to perform

Features

2. 0mm swiss 7075 t6 aluminium chassis with less rear flex

New pod and side link plates with 3 alignment positions to reduce bind

Aluminium pivot holders allow for a much lower roll-centre setting

Dual servo mounting options including a new floating servo holder

Wider front lower arms (+1mm each side) for better drivability

Thinner 1. 6mm carbon front brace enhances handling and mechanical grip

Redesigned front carbon bumper for increased durability

Centre dampener with improved sealing to prevent oil leakage

Tweak-free front suspension and rear pod system

Lightweight hollow steel rear axle for minimal rotating mass

Xray snap lock™ bushings for weight savings and easy maintenance

Fully adjustable geometry for camber, caster, toe, and more

Hudy spring steel™ high-tolerance pivot balls

Lightweight rear bulkheads with a cooling fan mounting point

Precision-moulded spur gears for quiet and dependable operation

Genuine xray product

Specifications

Length: n/a

Width: n/a

Height: n/a

Wheelbase: adjustable

Weight: n/a

Chassis: 2. 0mm swiss 7075 t6 aluminium

Suspension: kingpin front suspension with tweak-free system

Drivetrain: 2wd rear-wheel-drive direct drive

Motor: n/a

Esc: n/a

Included items

1x x12'26 chassis kit

Required items

2-channel radio system (transmitter & receiver)

Low-profile steering servo

1/12 scale motor & esc

1s lipo battery & compatible charger

1/12 scale wheels & tyres

1/12 pan car body shell & polycarbonate paint

Pinion gear

Assembly tools

Silicone oils & grease

Note

This is a competition-level assembly kit that requires full assembly.

All electronics, wheels, tyres, and body must be purchased separately.
