CAYOTE Racing ESC CREST X, Input (Cell): 2-3S Lipo COMING SOON
CAYOTE Racing ESC CREST X, Input (Cell): 2-3S Lipo COMING SOON
Couldn't load pickup availability
Out of stock
CREST X EVO
Exceptional Performance
and Processor Computing Power
The CREST X EVO is equipped with a high-performance ARM architecture, featuring a 32-bit Cortex-M4 core processor with a clock speed of up to 108MHz.
Compared to the CREST X the EVO can therefore achieve a 5 times higher computing power, enabling faster processing of complex calculations and therefore increasing acceleration and braking performance. This significant performance boost ensures stronger ability for high-speed response and multi-task controls, as well provides enhanced reliability and precision in high demand power applications.
Multiple Protection Features
The CREST X EVO is equipped with multiple reliability and protection features, ensuring safe and stable performance. Together, these features provide comprehensive safety and ensure optimal performance under various conditions.
Low Voltage Protection
Over Temperature Protection
Stall Protection
Fail-Safe Protection
Unlock Wireless Control with the BTUNE
Once the CREST X EVO is connected to the BTUNE module, a wireless connection can be established between your mobile device and the ESC. This allows for easy parameter adjustment, data reading, and firmware updates via the mobile app—convenient and user-friendly.
*”BTUNE is BQB certified for Bluetooth compliance. (BTune Module sku：CACBM01 （Sold separately）)
1/10 RACING ESC
Speed-up Revolution
Under the same parameters, burst power is increased by
While launch acceleration and brake control is improved up to
With up to 64 degrees of Boost and Turbo timing, the all new EVO delivers instant acceleration, making every launch lightning-fast and providing unmatched power support. Compared to the previous CREST X model, the EVO features superior processing speed, finer control, and enhanced burst performance.
Improved Throttle and Brake PWM Frequency Adjustment precision
The Crest X EVO offers a highly APP customizable experience with its adjustable PWM frequency for both throttle and brake. This feature allows users to fine-tune the throttle response and braking power to meet specific driving preferences and track conditions in even the smallest details, as well optimizing setup functionality.
CREST X EVO Specs
Continuous/Peak Current
160A / 1100A
BEC Output
Ultra-stable switch Vregulation 6V/7.4V; cont. current 6A/8A peak
Support Vehicle Type
1/10th TC; 1/10th Off Road/Etc.
Dimension
37.9 x 37.8 x 30mm (LxWxH)
Weight
55g
Cooling Fan
25x25x10mm, 6-7.4V BEC
Basic Information
Compatibility
- Motor: 1/10th TC≥4.5T；1/10th Off Road≥5.5T
- Motor Mode: Sensored and Sensorless Brushless Motors
- Battery: 2S LiPo
Wire Gauge
- Output Wires: Black-13AWG-180MM*3
-
Input Wires: Red-13AWG-180MM*1
Black-13AWG-180MM*1
ESC Programming Via
- Xlink Program Box Compatible
- B-Tune Connect (Optional)
- Internal Program (Port)(APP Control)
